linear-actuator

Linear actuators are a marriage of stepper motor with hollow shaft, spindle and nut. The advantage of this design is that they can absorb high axial forces at which conventional stepper motors cannot keep up. A large product portfolio can be drawn on for the spindles, which include, for example, steep thread, trapezoidal thread and metric thread spindles, as well as various metals. In addition, the spindle length and the threaded nut (flange threaded nut) available as standard are configurable. NEMA 11, 17 and 23 - flange size 28 mm, 42 mm and 56 mm are available in the online store. Optionally, an encoder can be added to each size.

Categories
Filters
Size
Electrical information
Design
Number of products 6

drylin® E linear actuator, stranded wires with JST connector, NEMA11

drylin® E linear actuator, stranded wires with JST connector, NEMA11
  • Installation size Motor: NEMA11 / Flange dimension 28mm
  • Protection class: IP40
  • Holding torque: 0.12Nm
  • Rated current: 1.00A
  • Linear feed/1.8° step: 0.0254mm
  • Force: 50N
  • Motor connection: stranded wires with JST connector
  • Efficient dryspin® high helix thread: DST 6.35x5.08
  • Lubrication-free dryspin® lead screw nut: 15mm
NZD 405.63/Pc.Cost-effective price break available onlineNZD 376.80/Pc. 10 Pc.

1 variant(s), of which:

igus-icon-lieferzeit-dot
1 ready for shipping in 24 - 48 hours

drylin® E linear actuator, stranded wires with JST connector, NEMA17

drylin® E linear actuator, stranded wires with JST connector, NEMA17
  • Installation size Motor: NEMA11/Flange dimension 42mm
  • Protection class: IP40
  • Holding torque: 0.50Nm
  • Rated current: 1.80A
  • Linear feed/1.8° step: 0.075mm
  • Force: 100N
  • Motor connection: stranded wires with JST connector
  • Efficient dryspin® high helix thread: DST 8x15
  • Lubrication-free dryspin® lead screw nut: 20mm
NZD 443.90/Pc.Cost-effective price break available onlineNZD 411.80/Pc. 10 Pc.

1 variant(s), of which:

igus-icon-lieferzeit-dot
1 ready for shipping in 24 - 48 hours

drylin® E linear actuator, stranded wires with JST connector and encoder, NEMA11

drylin® E linear actuator, stranded wires with JST connector and encoder, NEMA11
  • Installation size Motor: NEMA11/Flange dimension 28mm
  • Protection class: IP40
  • Holding torque: 0.12Nm
  • Rated current: 1.00A
  • Linear feed/1.8° step: 0.0254mm
  • Force: 50N
  • Motor connections: stranded wires with JST connector, encoder with JST connector
  • Efficient dryspin® high helix thread: DST 6,35x5,08
  • Lubrication-free dryspin® lead screw nut: 15mm
NZD 694.96/Pc.Cost-effective price break available onlineNZD 651.66/Pc. 10 Pc.

1 variant(s), of which:

igus-icon-lieferzeit-dot
1 ready for shipping in 24 - 48 hours

drylin® E linear actuator, stranded wires with JST connector, NEMA23

drylin® E linear actuator, stranded wires with JST connector, NEMA23
  • Installation size Motor: NEMA23/Flange dimension 56mm
  • Protection class: IP40
  • Holding torque: 2.00Nm
  • Rated current: 4.20A
  • Linear feed/1.8° step: 0.06mm
  • Force: 500N
  • Motor connection: stranded wires with JST connector
  • Efficient dryspin® high helix thread: DST 10x12
  • Lubrication-free dryspin® lead screw nut: 25mm
NZD 706.70/Pc.Cost-effective price break available onlineNZD 660.82/Pc. 10 Pc.

1 variant(s), of which:

igus-icon-lieferzeit-dot
1 ready for shipping in 24 - 48 hours

drylin® E linear actuator, stranded wires with JST connector and encoder, NEMA17

drylin® E linear actuator, stranded wires with JST connector and encoder, NEMA17
  • Installation size Motor: NEMA11/Flange dimension 42mm
  • Protection class: IP40
  • Holding torque: 0.50Nm
  • Rated current: 1.80A
  • Linear feed/1.8° step: 0.075mm
  • Force: 100N
  • Motor connections: stranded wires with JST connector, encoder with JST connector
  • Efficient dryspin® high helix thread: DST 8x15
  • Lubrication-free dryspin® lead screw nut: 20mm
NZD 750.00/Pc.Cost-effective price break available onlineNZD 702.56/Pc. 10 Pc.

1 variant(s), of which:

igus-icon-lieferzeit-dot
1 ready for shipping in 24 - 48 hours

drylin® E linear actuator, stranded wires with JST connector and encoder, NEMA23

drylin® E linear actuator, stranded wires with JST connector and encoder, NEMA23
  • Installation size Motor: NEMA23/Flange dimension 56mm
  • Protection class: IP40
  • Holding torque: 2.00Nm
  • Rated current: 4.20A
  • Linear feed/1.8° step: 0.06mm
  • Force: 500N
  • Motor connections: stranded wires with JST connector, encoder with JST connector
  • Efficient dryspin® high helix thread: DST 10x12
  • Lubrication-free dryspin® lead screw nut: 25mm
NZD 979.95/Pc.Cost-effective price break available onlineNZD 920.41/Pc. 10 Pc.

1 variant(s), of which:

igus-icon-lieferzeit-dot
1 ready for shipping in 24 - 48 hours
